CALB L221N113A NMC NCM Square Cell 3.7v 113 AH Lithium-ion roj teeb Cell

Lus piav qhia luv luv:

Lub CALB L221N113A NMC roj teeb yog lub roj teeb lithium-ion ua haujlwm siab nrog lub zog ntawm 3.7V thiab muaj peev xwm ntawm 113Ah.Lub roj teeb yog tsim los rau ntau yam kev siv, tshwj xeeb tshaj yog rau cov tsheb hluav taws xob, kev siv hluav taws xob tauj dua tshiab thiab lub tsev txhab nyiaj fais fab.Lub CALB L221N113A nta NMC (Nickel Manganese Cobalt) chemistry uas ua kom muaj zog ua haujlwm zoo thiab ua haujlwm ntev.Nrog nws lub peev xwm ua tau zoo, nws tuaj yeem muab cov khoom siv hluav taws xob ruaj khov thiab zoo ib yam rau lub sijhawm ntev.Lub roj teeb kuj tseem muaj kev ruaj ntseg zoo kom muaj kev tiv thaiv tiv thaiv overcharge, overheating thiab luv circuits.CALB L221N113A NMC roj teeb yog tsim nrog cov ntaub ntawv zoo thiab cov cuab yeej siv siab heev los lav kev ua haujlwm zoo thiab ua haujlwm ntev.

High Consistency
Nto moo Brand
Slim Loj
Siab zog

Tau txais QUOTATION

Product Detail

Khoom cim npe

Prismatic NCM Cell

Nws yog tsim los tiv thaiv kev ua haujlwm hnyav thiab tseem txhim khu kev qha txawm nyob hauv qhov kub thiab txias thiab qhov chaw nyuaj.CALB L221N113A NMC roj teeb uas muaj peev xwm thiab kev xa hluav taws xob zoo heev yog qhov kev xaiv zoo tshaj plaws rau cov ntawv thov uas xav tau lub zog ntev thiab txhim khu kev qha.Kev nqis peev hauv lub roj teeb lithium-ion no kom txuag tau lub zog thiab txhim khu kev qha hauv koj cov haujlwm.

CALB prismatic NMC roj teeb hlwb muaj npe nrov rau lawv qhov tshwj xeeb zoo thiab kev ua haujlwm zoo.Nrog lub peev xwm ntawm 113 ampere-teev thiab ua haujlwm ntawm 3.7 volts, Cov Qib A no muaj lub zog zoo dua qub thiab lub neej ntev mus ntev.NMC chemistry tawm tsam qhov sib npaug zoo ntawm lub zog ntom ntom thiab cov khoom siv hluav taws xob, ua rau lawv zoo tagnrho rau kev daws teeb meem tsheb hluav taws xob.Cov txheej txheem kev nyab xeeb muaj zog tiv thaiv kev tiv thaiv overcharge, over-discharging, thiab luv circuits.Xaiv CALB prismatic NMC roj teeb hlwb kom txhim khu kev qha thiab muaj kev nyab xeeb hauv ntau daim ntawv thov.

Kev Tswj Lub Neej Tag Nrho

Roj teeb lub neej Cycle tswj
High Consistency ntawm kev ua tau zoo

Dimensional Standard

Ntsib ntau yam
qhov ntsuas qhov ntsuas

Ib puag ncig phooj ywg

Dhau ib puag ncig
system ntawv pov thawj

Kev ruaj ntseg

Kev ua tau zoo heev nyob rau hauv qis kub
Zoo ib puag ncig adaptability

Lub neej ntev

ntev lub neej voj voog
Txog 2000 zaug

Ultra Safe

Kev tawg-pov thawj, Anti-luv Circuit Court tsim
kev nyab xeeb kev ua haujlwm siab

Daim duab loj

Nws yog tsim los tiv thaiv kev ua haujlwm hnyav thiab tseem txhim khu kev qha txawm nyob hauv qhov kub thiab txias thiab qhov chaw nyuaj.CALB L221N113A NMC roj teeb nrog hig (1)

Khoom Parameters

Hom	CALB
Qauv nab npawb	L221N113A
Hom	NCM
Nominal Peev Xwm	113.5 Aw @ 1C
Hom Voltage	3.7v ua
AC Internal Resistance	0.4 ~ 0.6mΩ
Standard them thiab tso tawmCharge / Discharge Current	0.5C / 0.5C
Standard them thiab tso tawmCharge / Discharge Cut-off Voltage	4.35V / 2.8V
Nruam Charge / Discharge Current	1 C/1 C
Cia Humidity	70﹪ RH
Muaj peev xwm tuav tau nyob rau hauv chav tsev kub	Muaj peev xwm tuav tau ≥94%
Maximum Pulse Discharging Tam Sim No (Short Pulse)	500 A
Pom zoo SOC qhov rais	5% -97%
Kev them nyiaj ua haujlwm kub	-20 ℃ ~ 55 ℃
Tshem Tawm Ua Haujlwm Kub	-30 ℃ ~ 55 ℃
Loj (H * W * T)	105.88 * 220.8 * 33.36 hli
Qhov hnyav	1800 ± 25g
Plhaub Khoom	Aluminium alloy
Lub neej voj voog	≥2000 zaug

Hluav taws xob Performance Diagram

1.Thermal-Electrochemical Coupled Model

2.Tag nrho J/R thiab Stack Model

3.Chaw thiab tawm nkhaus: sib piv ntawm simulation thiab qhov tseeb ntsuas qhov tseeb

Daim duab pob

Nto moo Brand Chaw tsim tshuaj paus

Cov kab ntau lawm

Daim ntawv pov thawj khoom

Txhawb koj lub ntiaj teb nrog CALB NCM roj teeb hlwb - Unleashing boundless zog rau lub neej yav tom ntej ci.

CALB NCM roj teeb hlwb muab lub zog tsis muaj zog, ua rau lub neej yav tom ntej zoo dua rau lub ntiaj teb thiab txhawb kev lag luam nrog lawv lub zog tshwj xeeb thiab kev ua haujlwm zoo.Cov roj teeb siab tshaj plaws no muab kev ua haujlwm tsis sib xws, ua kom lub zog siv tau ntev dua thiab muaj zog dua kev daws teeb meem rau ntau yam kev siv.Txawm hais tias nws yog lub tsheb fais fab, lub tshuab hluav taws xob tauj dua tshiab, lossis daim phiaj cia, CALB NCM roj teeb lub hlwb tso tawm lub zog tsis muaj zog, txhawb kev lag luam thiab cov tib neeg los puag lub neej huv thiab ci dua.Nrog lawv cov thev naus laus zis thev naus laus zis thiab kev ntseeg tau zoo dua, cov roj teeb roj teeb no tsav kev tsim kho tshiab thiab roj kev nce qib mus rau lub ntiaj teb muaj kev ruaj ntseg thiab muaj kev nyab xeeb dua.Siv lub zog ntawm CALB NCM roj teeb hlwb thiab koom nrog kev txav mus rau lub neej yav tom ntej uas muaj zog dua thiab muaj zog dua.
